TBS FPV RC Radio Controller

Description

Description

REDEFINING THE REMOTE CONTROL

Team BlackSheep has been at the forefront of perfecting the interface between FPV drone and mind. The TBS Tango 2 changes how radio remote controls will be from here on out! Despite being the smallest remote control available, it comes with full size HAll gimbals, full-featured FreedomTX (temporary OpenTX fork), the lowest end-to-end latency of any remote and transmission system, unbreakable 3 & 2-position switches, open source operating system, built-in battery, USB-C charging, and so much more! It's not just a retouched game controller, it was designed from the ground up for R/C! The form factor and features make it the ideal take-anywhere, fly-anytime remote control.

CROSSFIRE INSIDE

The first radio with TBS Crossfire built in. This significantly lowers your cost, increases reliability and minimizes set up time. And the cherry on top are the LUA scripts being part of the familiar user interface. The antenna swivels out of the way, or doubles as a kick-stand when resting. TBS Cloud ready to go from the start. It all just makes sense.

Features
Full size HAll sensor gimbals
Ball-bearing
Configurable resistance and tension
Adjustable throttle & pitch throw (+/- 10 degrees)
Spare spring set included for lower tension
Foldable gimbal sticks (Pro only)
Ergonomic and compact design with comfy rubber grips
Robust, streamlined switches
2x 2-position switches
2x 3-position switches
2x momentary buttons
TBS Crossfire built-in
CRSFShot for lowest latency and most direct response of any remote control available
Range of up to 30km / 20mi from the palm of your hand
Swivel-antenna that doubles as a kick-stand
Up to 12 channels supported
Built-in 5000mAh 1S LiPo with USB-C 2A charging (2.5 hours for full charge)
Speech audio output with audio jack & haptic vibration alert
Open Source remote control operating system (FreedomTX, temporary fork of OpenTX)
Rocker dial and 3 button menu for super simple navigation
High resolution (128*96) black & white OLED screen w/ backlight
Digital rocker dial trim
100+ model memory with included SD-card
TBS Cloud compatible


This Slim TX module is designed by Happymodel and based on the open source- ExpressLRS which is a very popular low latency and high re-flashed rate RF module for RC Airplane and FPV Racing drone. Its main hardware architecture is ESP32, ESP8285 and SX1280 RF chip. The ES24TX Slim module is a complete solution which is already pre-load the Expresslrs firmware and it's plug and play for Frsky X-lite/X-lite pro/X9 Lite , TBS Tango2.

This Slim module comes with an aluminum alloy shell and is equipped with a cooling fan that automatically works when the module is working at 250mw.



Features:
Open source ExpressLRS
Long range, low latency and High re-flashed Rates
Supports up to 250mw RF power
Telemetry data transmission supported
Cooling fan provide
CNC aluminum protective shell




Specifications:

Regulatory Domain: ISM2400

MCU:ESP32(main),ESP8285(aux,as espbackpack)

RF chip:SX1280IMLTRT

Lite Frsky 8pin socket

Frequency Range: 2400 MHz to 2500 MHz

Maximum receive refresh rate: 500Hz

Minimum receiver refresh rate: 25Hz

RF Output Power: 10dBm~24dBm

Power supply voltage: 5v~10v

Weight: 48gram(with antenna and case)

Dimension: 60mm*30mm*20mm(With CNC case)

Antenna gain:1.87dBi



TBS TANGO 2 INCLUDES

• 1 x Tango 2 remote
• 1 x Springs Set (Lower Tension)
• 1 x Tango 2 Neck Strap Mount



TBS TANGO 2 PRO INCLUDES

• 1 x Tango 2 Pro
• 1 x Velvet Carry Bag with TBS Logo
• 1 x Springs Set (Lower Tension)
• 2 x Throttle limitation screws (with allen key)
• 1 x Sticker Sheet
• 1 x Tango 2 3D KeyChain (will only be included in the first run)
• 1 x Tango 2 Neck Strap Mount
